FLYiNG 零件編號 | ICR1MX55GADJAB5RUTC |
FLYiNG 庫存現貨 | 30 |
製造商 | UTC |
製造商零件編號 | R1MX55G-ADJ-AB5-R |
說明 | LINEAR IC R1MX55G-ADJ-AB5-R SOT-89-5 |
無鉛狀態 / RoHS 指令狀態 | RoHS / Halogen Free |
電源管理 LDO | LINEAR INTEGRATED CIRCUIT |
製造商 | UTC |
系列 | R1MX55 |
原廠料號 | R1MX55G-ADJ-AB5-R |
輸入電壓VIN | 2.6~9.0V |
輸出電壓Vout | 1.3~5.0V |
靜態電流IQ | 0.8mA |
功耗 | 900mW |
工作溫度 | -40~85°C |
封裝/外殼 | SOT-89-5 |
安裝類型 | SMD 表面黏著式 |
無鉛狀態 RoHS | RoHS / Halogen Free |
標準包裝數量 | 4000/Reel Tape Reel 捲裝 |
R1MX55 LINEAR INTEGRATED CIRCUIT
VOLTAGE REGULATOR
DESCRIPTION
As the UTC linear intergrated LDO, the R1MX55 shows a high current, high accuracy, low-dropout voltage. The feature are: low dropout voltage, very low ground current. Cause the series have been designed for high current loads, so they are also used in lower current, extremely low dropout-critical systems (in which their tiny dropout voltage and ground current values are
important attributes).
The R1MX55 is stable with ceramic capacitors. It requires a 1μF or greater capacitor for stability.
FEATURES
R1MX55 線性集成電路
電壓調節器
說明
R1MX55作為UTC線性集成LDO,具有大電流、高精度、低壓差的特點。 特點是:低壓差,極低的接地電流。 因為該系列是為高電流負載而設計的,因此它們也用於低電流、極低壓差臨界系統(其中它們的微小壓差電壓和接地電流值是
重要屬性)。
R1MX55 使用陶瓷電容器時很穩定。 它需要一個 1μF 或更大的電容器以確保穩定性。
特徵
VOLTAGE REGULATOR
DESCRIPTION
As the UTC linear intergrated LDO, the R1MX55 shows a high current, high accuracy, low-dropout voltage. The feature are: low dropout voltage, very low ground current. Cause the series have been designed for high current loads, so they are also used in lower current, extremely low dropout-critical systems (in which their tiny dropout voltage and ground current values are
important attributes).
The R1MX55 is stable with ceramic capacitors. It requires a 1μF or greater capacitor for stability.
FEATURES
- Available and fixed output versions 1.5V, 1.8V, 2.5V, 3.3V, 5V
- Built-in ON/OFF function
- Over current protection function
- Over heat protection function
- Adjustable DC output voltage
R1MX55 線性集成電路
電壓調節器
說明
R1MX55作為UTC線性集成LDO,具有大電流、高精度、低壓差的特點。 特點是:低壓差,極低的接地電流。 因為該系列是為高電流負載而設計的,因此它們也用於低電流、極低壓差臨界系統(其中它們的微小壓差電壓和接地電流值是
重要屬性)。
R1MX55 使用陶瓷電容器時很穩定。 它需要一個 1μF 或更大的電容器以確保穩定性。
特徵
- 可用和固定輸出版本 1.5V、1.8V、2.5V、3.3V、5V
- 內置開/關功能
- 過流保護功能
- 過熱保護功能
- 可調直流輸出電壓
