商品項目:15803
庫存現貨

圖片僅供參考
S-24C02DI-T8T1U5 8-Pin TSSOP ABLIC
附件下載
商品名稱 2-WIRE SERIAL E2PROM 2線串行E2PROM
訂購數量
依數量訂價
15 NTD
FLYiNG 零件編號 ICS24C02DIT8T1U5ABLIC
FLYiNG 庫存現貨 10
製造商 ABLIC
製造商零件編號 S-24C02DI-T8T1U5
說明 S-24C02DI-T8T1U5 8-Pin TSSOP ABLIC
無鉛狀態 / RoHS 指令狀態 RoHS
訂購數量 NTD 單價 / PCS
1~9 15
10~99 10
封裝/外殼 8-Pin TSSOP
標準包裝數量 4000/REEL 捲軸
S-24C02D/04D/08D/16D
2-WIRE SERIAL E2PROM

This IC is a 2-wire, low current consumption and wide range operation serial E2PROM. This IC has the capacity of 2 K-bit,
4 K-bit, 8-K bit and 16 K-bit, and the organization is 256 words x 8-bit, 512 words x 8-bit, 1024 words x 8-bit and 2048 wordsx 8-bit,
respectively. Page write and sequential read are available.
---------------------------------------------------------------------------------------------
S-24C02D/04D/08D/16D
2 线串行E2PROM

本IC是消耗電流低、工作電壓範圍廣的2線串行E2PROM。容量為2 K位、4 K位、8 K位、16K位,構成為256字x 8位、512字x 8位、1024字x 8位、
2048字x 8位。可進行頁寫入和順序讀出。
